Barge and Tug | Tuticorin to Maldives





barge for boulders, rock, construction, sand, ODC, ramp, sidewall, India, Maldives, Tuticorin
Flat Top Barge with ramp







Flat top barges with side wall and Ramp are in demand for carrying construction material from Tuticorin India to Maldives.

The barges are available with high deck strength so that they can be capable of loading and carrying rock boulders which are mainly used for filling and construction purpose.
Today these barges for carrying boulders are available on time charter for minimum one year contract. All these barges are without engine and pusher tug is required to tow or push these barges.

These barges are available in capacity of 3000 DWT to 5000 DWT or above. The pusher tug capacity also varies depending on the carrying capacity of the barge.
In India most of the barges are without engines and are mainly employed for transporting rock boulders from Tuticorin, Mangalore, etc port to Maldives.

















Opening Tuticorin,India,10th Oct 2011


VESSEL OPENING TUTICORIN 10TH OCTOBER 2011


- M/V "ST. ANDREW"; FLAG: LIBERIAN

- OFFICIAL NUMBER: 11520   IMO NUMBER: 9088392
- EX NAME OF VESSEL: SAN ANTONIO;  TYPE: DRY BULK CARRIER
- CALL SIGN: ELZS9; TELEX/PHONE/FAX: 463790662/764652447/764652449
- BUILT YEAR/MONTH: 1996/JAN/15. YARD: VARNA SHIPYARD BULGARIA
- MAKERS/ MODEL/HORSEPOWER OF MAIN ENGINE: BRIANSK - RUSSIA
. TYPE: BMZ MAN - B+W 6L60MC /11340HP-8340KW
. CLASS - HIGHEST RUSSIAN MARITIME REGISTER OF SHIPPING, MEMBER IACS
. GT/NET 25,190.00/14,197.00 - INTERNATIONAL
.        25.955.45/23,201.04 - SUEZ
.                 /20,960.00 - PANAMA
- WINTER/SUMMER/TROPICAL DWT AND RESPECTIVE DRAFT:
. winter  : 40,352 mt at 11.222 metres
. summer  : 41,499 mt at 11.460 metres
. tropical: 42,651 mt at 11.698 metres
- TPC: 48.17 AT SUMMER DISPLACEMENT
- CONSTANTS EXCLUDING FW: 450MT; LIGHT WEIGHT 9,350 MT; FWA 265 MM
- TANKS CAPACITIES (MT): IFO 1,787; MDO 236; FW 428, BALLAST 14,365.6
- LOA: 186.45 m, BEAM: 30.00 m, MOULDED DEPTH 16.20 M, LBP: 177.00 M
- CFT GRAIN - TOTAL - 1,852,466, HOLDWISE:
. H1-337,184  H2-379,668  H3-378,997  H4-381,010 H5-375,607
- CFT BALE -  TOTAL - 1,794,268, HOLDWISE:
. H1-323,694  H2-369,780  H3-369,144  H4-371,087  H5-360,563
- DISTANCE FM WATERLINE TO TOP OF HATCHCOVERS/HATCH COAMING UNDER OPEN
. CONDITION AT HOLDS 1/3/5 WHEN LOADED/LIGHT BALLAST HEAVY BALLAST (M):
. HOLD 1 - 7.80/14.90/12.00; 3 - 7.04/13.15/10.70; 5 - 6.80/12.00/9.85
. DISTANCE FM WATERLINE TO HIGHEST POINT:
. LIGHT BALLAST - 40.4 M, HEAVY BALLAST - 38.1 M, FULLY LADEN - 35,0 M
- Hold . nbr 3 to be flooded and ballast pump capacity 2 x 600 cbmtr/hr.
- NO. OF HOLDS/HATCHES: 5/5; CO2 FITTED
- HATCH COVERS TYPE: FOLDING HYDRAULIC, TYPE A72X
- NUMBER OF GEAR/GRABS AND ITS CAPACITY (WT/CBM):
. 4 x swl 30mt electrohydraulic cranes, 4 x 6/9/12 cbm grabs.
- when crnes working on grab duty the total weight of grab+cgo not
. to exceed the 25 mt.
- MAX OUTREACH OF GEAR WITH ITS MAX SWL:
. Maximum radius 24mtr at swl of 30mt
. Maximum outreach over ship's side 9 mtrs.
- ALLOCATION OF GEAR: Between Holds Nos: 1-2, 2-3, 3-4, 4-5 on center line
- DIMENSION HATCHES:
. NO.1 - 19.72 x 15.35 mtr and nos 2,3,4,5 - 19.89 x 15.36
- DIMENSION TANKTOP:
. HOLD 1 - L 25.80 x Bfwd 6.40 x Baft 21.80 mtr
. HOLD 2 - L 25.20 x B 22.00 mtr
. HOLD 3 - L 25.20 x B 22.00 mtr
. HOLD 4 - L 25.20 x B 22.00 mtr
. HOLD 5 - L 26.70 x Bfwd 22.00 x Baft 16.00 mtr
- STRENGTH OF TANKTOP, MAIN DECK HATCH COVERS RESPECTIVELY:
. TANK TOP :19.0 mt/m2; DECK : 2.0 mt/m2 (outside of hatch
. ways with tstks empty); HATCH COVERS: 1.75 mt/sqmtr
. applicable for uniform/homogenuous bulk or flat base breakbulk cgoes.
SPEED/CONS ABT 13.0 KNOTS ON ABT 25.0 MT IFO MAXIMUM 180 CST GRADE RME180
(ISO 8217:2005(E) PLUS ABT 2.0 MT MDO ISO 8217:2005(E) DESIGNATION
ISO-F-DMB AVERAGE LADEN AND BALLAST IN GOOD WEATHER CONDITIONS DEFINED AS
MAX BEAUFORT FORCE 4 AND DOUGLAS STATE 3 IN PORT ABT 2.0 MTS MDO PLUS ABT
1.2 MT IFO FOR AUX BOILER IDLE AND ABT 3.8 MT MDO PLUS ABT 1.2 MT IFO
WORKING. VESSEL BURNS MDO WHEN MANEOUVERING, IN NARROW
WATERS/CANALS/RESTRICTED AREAS AND IN/OUT PORTS.
ALL DETAILS "ABOUT",
